Manten Brand sewer cleaning truck is also called drainage vacuum truck, the sewage cleaning truck. This sewer flusher truck is a new type of special sanitation vehicle that combines the functions of a high-pressure cleaning vehicle and a sewage suction truck. The highlight function of the vacuum sewage truck is to dredging the sewer blocked areas that cannot be reached by manpower, so it is called a drainage vacuum truck. Other functions of the car are floor flushing, sewage suction and sewage discharge, landscaping and so on.
The working principle of storm drain cleaning truck is that after absorbing the accumulated water in the sewer through the sewage suction pipe system, the vehicle-mounted winch places the high-pressure pipe at a constant speed. When the high-pressure flushing pipe is working, the rotating force makes the high-pressure flushing pipe enter the sewer blocked area that cannot be reached by manpower, and perform high-pressure flushing operation. Through the sewage suction pipe, the coverage of the blocked area by the water sewage can be minimized to achieve the best flushing effect and achieve the purpose of dredging the sewer.
SPECIFICATION | |||
Truck Specification | |||
Product Name | Sewer cleaning Truck | ||
Truck Manufacturer | MANTEN GROUP | ||
Chassis Specification | |||
Chassis brand | Dongfeng , Foton, Sinotruk Howo, ISUZU, FAW ,NORTH BENZ, JAC, CAMC , | ||
Drive type | 4X2 ,6X4,8X4, 4X4, 6X6,8X8 | ||
Engine brand | Cummins, ISUZU ,Wechai, Yuchai, Yunnei | ||
Transmission brand | Fast ,ZF , Manual/ ATM | ||
Tire brand | Tri-angle, Double Coin, Good year ,Michelin | ||
Vehicle Description | |||
GVW | 7300kg-31000 kg | ||
Tanker Description | |||
Dredging System | High-pressure Water Pump | Model | HPP/MEC/ URACAKD708G |
Pressure | 21MPa | ||
Flow | 212L/min | ||
Clean Water Tank | Structure | Combination of Three Stainless Steel Tank | |
Volume | 5.8m³ | ||
Reel | Power | Hydraulic | |
Speed | 0~30m/min | ||
Length | 80m | ||
Diameter | φ150mm~φ800mm | ||
Vacuum Suction System | Vacuum Pump | Model | JUROPPVT200M |
Flow | 1280m3/h | ||
Suction Range | ≥6m | ||
Sewage Tank | Structure | Oval, Opening at the Back | |
Volume | 6.47m³ | ||
Tipping Angle | ≥45° | ||
Rotation Arm | Control | Up & Down, Left & Right, Extention & Retract | |
Vertical Angle | -3~40° | ||
Rotation Angle | 180° | ||
Extention Rangle | 1300mm | ||
Sewage Suction Pipe | Material | PVC | |
Diameter | 5 | ||
Length | 6m |
1. High brand recognition. Well-known brands or more familiar brands are often preferred by users, and the choice of drainage vacuum trucks are largely influenced by brands. The manten sewer jetter truck for sale has been sold to many overseas countries and has been well received.
2.The appearance of the combination sewer cleaning truck for sale is good. With the continuous advancement of sludge cleaning truck technology, the manufacturing process of modern sdrain cleaning lorry has become very mature. All sewer cleaning trucks produced by manten adopt international advanced jetting and cleaning technology. Which had huge water pressure. That will help the sewer cleaning quickly.
3. The price of sewer cleaning truck is more favorable. Mantern sludge cleaning trucks are directly sold by manufacturers, and the price transparency of such sludge cleaning trucks will be higher and more easily accepted by users.
I.Cabin Preparation
1.Start the truck.
2.Press the clutch, start up the PTO, and meanwhile put the low-speed 5th gear, and finally lift the clutch slowly, then the vehicle enters the working state.
II.Sewage Suction Operation
1.Push the rear door lever inward to ensure it is fully closed.
2.Manually lock both rear door switches.
3.Operate the boom rise through the control rod of rear platform, select the boom rotation direction according to the working position, and control the boom extension and retraction through the middle control rod. Finally, manually put the suction pipe to the target position.
4.Open the pneumatic valve of the boom.
5.Open the vacuum pump valve, and the vehicle starts to absorb sewage normally. Confirm the suction volume by the level gauge beside the tank.
6.After finishing the suction, close the vacuum pump valve and pneumatic valve. Manually pull the suction pipe out of the working area, retract the boom, rotate the boom to the middle position, and lower the boom. Then press the clutch, close the PTO, and put the gear back in neutral. The sewage suction operation is finished.
III.Sewage Discharge Operation
1.Open the rear discharge valve, and the sewage is discharged.
2.Once the sewage flow from the outlet is small, manually unlock the two rear door switches.
3.Start the truck, press the clutch, start up the PTO, and meanwhile put the low-speed 5th gear, and finally lift the clutch slowly, then the vehicle enters the working state. Pull the rear door control lever outwards, the rear door slowly opens. Lift up the tank through the control lever to discharge the remaining sewage.
4.After discharging all the sewage, lower the tank through the control rod. Close the rear door through the control rod, and manually lock the two rear door switches. Then press the clutch, close the PTO, and put the gear back in neutral. The sewage discharge operation is finished.
Note:
(1) If the vehicle does not work for a long time, discharge the pipe residual water. Open this drain valve and the rear reel drain valve, the residual water will be drained out by the air pressure.
(2)Open the secondary anti-overflow valve regularly to discharge residues.
(3)The suction sewage volume shall not exceed the red line area of the liquid level meter.
(4)Before sewage operation, unlock the rear door switches and then open the rear door.
Tank body: The tank body of the sewr cleaning truck is made of 4-6MM carbon steel plate straight seam welding, the sewage tank body is made of 6-10MM carbon steel, and the tank head is made of 10-12MM, and the interior can be customized according to customers. Preservative treatment is required.
Tank body: The tank body of the sewr cleaning truck is made of 4-6MM carbon steel plate straight seam welding, the sewage tank body is made of 6-10MM carbon steel, and the tank head is made of 10-12MM, and the interior can be customized according to customers. Preservative treatment is required.
Special power unit: High-pressure water pump, vacuum pump, sewage dumping and self-unloading device.
Special power unit: High-pressure water pump, vacuum pump, sewage dumping and self-unloading device.
The pipeline system : Consists of pipelines, water inlets, self-flow openings, sewage outlets, high-pressure flushing pipelines, sewage suction pipelines, and hydraulic control pipelines.
The pipeline system : Consists of pipelines, water inlets, self-flow openings, sewage outlets, high-pressure flushing pipelines, sewage suction pipelines, and hydraulic control pipelines.
Operating system: The special vehicle chassis drives the high-pressure water pump, vacuum pump and hydraulic pump to work through the power take-off, and the hydraulic control pipeline of the hydraulic pump realizes the system control of the high-pressure water pump, vacuum pump, winch, etc.
Operating system: The special vehicle chassis drives the high-pressure water pump, vacuum pump and hydraulic pump to work through the power take-off, and the hydraulic control pipeline of the hydraulic pump realizes the system control of the high-pressure water pump, vacuum pump, winch, etc.
