Name: ISUZU 3ton Integrated Tow Truck
Brand: Hubei Manten Automobile Co., Ltd.

Specification Of ISUZU 3ton Integrated Tow Truck

SPECIFICATION
Truck Specification
Product Name		isuzu 3ton integrated Tow Truck
Truck Manufacturer		MANTEN GROUP
Overall dimensions (L×W×H)		About 600022002400mmmm
Chassis Specification
Cabin		isuzu elf cabin, with air conditioner
Drive type		4*2
wheelbase		3360mm
Fuel type of engine		Diesel
Engine	Model	4KH1CN5LS
	Maximum horse power	98hp
	Number of cylinders	4
	Emission standard	Euro 5
Gear box	Type	MSB, MANUAL, 5 forwards and 1reverse
Tyres	Size	7.00R16
	Quantity	6+1 spare tire
Upper body specification
Platform	Standard configuration	With two section hexagonal arm, a supporting section arm mechanism (hydraulic cylinder) and ITALY valves. With towing winch device and 45 meters steel rope.
Function	Equipped with hydraulic lifting mechanism (winch).
	Equipped with supporting arm mechanism (hydraulic cylinder).
	Equipped with luffing mechanism (lifting boom, hydraulic cylinder).
	Equipped with electronic control.
